אקסס פוינט חיצוני Tp-Link WBS210 N-300

Hardware

Included Power Adapter

No

PoE

Yes

Ethernet Port

5

Optical Port

2

Ethernet Port Speed

10 Mbps/100 Mbps/1000 Mbps

Optical Port Speed

1000 Mbps

Console Port

1

Power Supply Mode

48 V–57 V DC

Operating Temperature

–40 °C to +75°C (–40 °F to +167 °F)

Operating Humidity

10%–90% (RH)

Power Consumption

Idling: ≤ 9 W
Full load: 120 W

Performance

Layer

L2

Managed

Yes

Switching Capacity

14 Gbps

Packet Forwarding Rate

10.42 Mpps

Packet Buffer Size

1.75 Mbits

Communication Standard

IEEE 802.3i; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3x; IEEE 802.3z

MAC Table Size

4K

Function

PoE Protocol

IEEE 802.3af (PoE); IEEE 802.3at (PoE+); Hi-PoE; IEEE 802.3bt

PoE Power

Port 1-2: ≤ 90 W
Port 3-5: ≤ 30 W
Total: ≤ 120 W

PoE Power Consumption Management

Power consumption management
PoE power on and off
Power off when PoE power is overloaded
Green PoE

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE Transmission

Yes

Jumbo Frame

9,000 bytes

Spanning Tree Protocol

ERPS

VLAN Function

802.1Q

Flow Control

Full-duplex flow control (back pressure)
Full-duplex flow control (PAUSE)

Link Aggregation

Static link aggregation; LACP

Port Mirroring

Multiple-to-one port mirroring

Multicast

Yes

DHCP Function

DHCP client
DHCP-Server
DHCP-Snooping

Security

User management
HTTPS
SSH
SNMP V1/V2C/V3
ACL
802.1x
Loop protection

QoS

CoS/DPL based QoS
8 output queue for each port
Port shaping
SP, WRR queue scheduling
DSCP-based QoS

Maintenance

Uploading/downloading configuration files
Online upgrade
System logs

Device Management

Web ; SNMP; CLI

General

Statics Protection

Air discharge: 15 kV
Contact discharge: 8 kV

Lighting Protection

Common mode: 6 kV
Differential mode: 4 kV

Net Weight

0.65 kg (1.43 lb)

Gross Weight

2.8 kg (6.17 lb)

Product Dimensions

94.4mm × 53.5 mm × 135 mm (3.7” × 2.11”× 5.31″) (L × W × H)

Packing Dimensions

254 mm × 187 mm × 101 mm (10.00” × 7.36”× 3.97″) (L × W × H)
